Complete block mould
Forms the lightweight block billet; the delivered geometry follows the selected product.
Compare line configurations
EQUIPMENT GALLERY
Real equipment photos and engineering views
Open any image to inspect the original full-size media.
STANDARD EQUIPMENT PARAMETERS
Model, dimensions, power, weight and function
Standard catalogue parameters. Capacity-specific quantity remains in the production-line configuration table below.
| Variant | Model | Dimensions | Rated power | Reference weight | Function |
|---|---|---|---|---|---|
| 3 m block mould | HDCM1-004 | 3000 × 600 × 840 mm | — | 940 kg | Long mould for the confirmed lightweight block product. |
| Square mould | HDCM1-001 | 1230 × 1230 × 630 mm | — | 300 kg | Square mould for the confirmed lightweight block product. |
| Square mould base | HDCM1-002 | 1336 × 1336 × 180 mm | — | 120 kg | Supports the square mould during pouring, curing and transfer. |
| Wall-panel mould | HDCM1-003 | 3000 × 840 × 630 mm | — | 780 kg | Long mould for the confirmed wall-panel product. |
| 2.4 m block mould | HDCM1-005 | 2400 × 600 × 840 mm | — | 820 kg | Long mould for the confirmed lightweight block product. |
Reference parameters describe the listed equipment model. Final interfaces, voltage, quantity and delivered configuration are confirmed in the project quotation and engineering drawings.
PRODUCTION-LINE CONFIGURATIONS
Configuration options by production line
The highlighted row matches the production line you selected. Final model, dimensions, quantity and power are confirmed during project engineering.
| Production line | Model | Dimensions | Qty. | Unit power | Total |
|---|---|---|---|---|---|
| 50 m³/day → | HDCM1-002 | 1.2 m × 1.2 m × 0.62 m | 1 | — | — |
| 100 m³/day → | HDCM1-002 | 1220 × 1220 × 630 (complete set) | 1 | — | — |
| 200 m³/day → | HDCM1-002 | 1220 × 1220 × 630 (complete set) | 1 | — | — |
| 300 m³/day → | HDCM1-002 | 1220 × 1220 × 630 (complete set) | 1 | — | — |
| 400 m³/day → | HDCM1-002 | 1220 × 1220 × 630 (complete set) | 1 | — | — |
| 600 m³/day → | HDCM1-002 | 1220 × 1220 × 630 (Complete Set) | 1 | — | — |
| 1000 m³/day → | HDCM1-001 | 1420 × 1220 × 630 | 1162 | — | — |
